NUVIS wired NVR system - 4 armored cameras

NUVIS wired NVR system - 4 armored cameras

Regular price $1,395.00
Regular price Sale price $1,395.00
Sale Sold out
Shipping calculated at checkout.
View full details

About This Product

Wouldn't it be nice if you could always have eyes on every corner of your store? While you can't physically be everywhere all the time, the Nuvis IP wired four camera kit can. These four armored cameras work together to provide an integrated security system that allows you to know what goes on in every area of your store.



Installation is straightforward with four 100 foot cables included with your cameras. Each camera provides an autofocused 112-degree view from behind an armored dome.



Each HDD can hold up to 6TB worth of recordings. Plus each camera also has 128 GB of onboard storage.



Kit Features:

  • - 4 PoE Ports
  • - 5 Megapixel Recording Resolution
  • - 4 channel synchronous playback
  • - 720-pixel playback resolution
  • - HDMI/VGA outputs displaying at 1920 x 1080 pixels
  • -1 SATA HDD

Once you install your system, be sure to download the Guarding Expert app to your iPhone or Android phone for monitoring everywhere you go. Your system also comes with free DDNS service.

4 CHANNEL NVR SPECS :

NVR SPECS:



4ch Plug & Play PoE NVR

Features

-4 PoE  Port
-Up to 5 Megapixels Resolution Recording
-Up to 4 ch synchronous playback
at 720P resolution
-HDMI/VGA output at up to 1920×1080P
-1 SATA HDD

Video / Audio input

IP Video input 4 ch, 4PoE
Two-way Audio 1 ch, RCA

Video/Audio output

Recording resolution 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/



DCIF/2CIF/CIF/QCIF

HDMI/VGA output HDMI & VGA : simulation
Audio output 1 ch, RCA (Linear, 1kΩ)
Playback resolution 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Synchronous playback 4ch@720P, 2ch@1080P,1ch@5MP

Hard disk

Type 1 SATA interfaces
Capacity Up to 6TB capacity for each HDD

External Interface

Network interface 1 x RJ-45 10 /100 /1000 Mbps



4 x10 /100 Mbps PoE Ethernet

Input 40 Mbps
Output 80 Mbps
USB interface 2 x USB2.0

General

Power Supply 100~240VAC, 47~63Hz, 3A
Power Consumption 15 W (without hard disk)
Working Temperature -10 °C ~ +55 °C
Working humidity 10%~90%
Chassis 1U chassis
Dimensions 12.5” × 9.5” × 2”
Weight 4.5 lb

CMS/Web/Smart Phone

CMS iCMS
Web 4ch View/4ch Playback
Smart Phone Apps Guarding Expert ( iphone, android)



Guarding Expert HD(iPad)

DDNS Free DDNS service

CAMERA SPECS AND HIGHLIGHTS

4 Mega Pixel Auto Focus IR Vandal Camera

Features

-4 megapixel High Resolution
-20fps @ 2688×1520
-Low Illumination
-Auto-focus 2.8~12mm Varifocal lens
-3D DNR & 120dB WDR & BLC
-IP66 Rating
-IR Range up to 100ft
-True Day / Night
-Junction Box available
Conduit pipe holes
(1) 3/4″ NPT thread w/ Cap (Side)

Digital as well as optical zoom

Camera
Image Sensor 1/3″ Progressive Scan CMOS
Minimum Illumination 0.01 lux @F1.2, AGC ON,
0 lux with IR
Shutter Time 1/30s ~ 1/100,000s
Lens Auto-focus motorized 2.8~12mm @F1.4
Horizontal field of view 112°~33.8°
Lens Mount Φ14
Optical Filter Mechanically Switching IR Filter
Noise Reduction 3D DNR
WDR 120dB WDR
On-board Storage Micro SD/SDHC/SDXC card, Max 128 GB
Video Compression H.264/M-JPEG
H.264 Profile Main profile
Bit Rate 32 Kbps~16Mbps
Max Resolution 2688×1520
Frame Rate 20fps (2688×1520), 30fps (1920 × 1080), 30fps(1280×720)
Image Settings Saturation, brightness, contrast adjustable
BLC Yes, zone configurable
Network
Network Storage NAS
Alarm Trigger Line Crossing, Intrusion Detection, Motion detection,
tampering alarm, network disconnect, IP address conflict, storage  exception
Protocols TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP,
NTP, UPnP, ICMP,IGMP,SNMP, FTP, 802.1X, QoS, HTTPS
Compatibility ONVIF(Profile S&G), PSIA, CGI
General Functionalities (Security) dual stream, heartbeat, mirror, password protection, privacy mask,
watermark, IP address filtering, Anonymous access
Network Interface 1 RJ45, 10 M/100 M Ethernet port
General
Power Supply 12 V DC ± 10%; PoE (802.3af)
Power Consumption Max. 5.5W (7.5W with IR on)
Operating Temperature -30°C ~ 60°C (-22°F ~ 140°F) humidity 95% or less (non-condensing)
Impact Protection exceeding IK10
EXIR Range Up to 100ft
Dimensions 3.74” x 4.13” x10.18”
Weight 2 lb
Weather Proof IP66
