4ch Plug & Play PoE NVR
Features
-4 PoEย Port
-Up to 5 Megapixels Resolution Recording
-Up to 4 ch synchronous playback
at 720P resolution
-HDMI/VGA output at up to 1920ร1080P
-1 SATA HDD
NUVIS wired NVR system - 4 armored cameras
NUVIS wired NVR system - 4 armored cameras
Regular price
$1,969.00
Regular price
Sale price
$1,969.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
About This Product
Wouldn't it be nice if you could always have eyes on every corner of your store? While you can't physically be everywhere all the time, the Nuvis IP wired four camera kit can. These four armored cameras work together to provide an integrated security system that allows you to know what goes on in every area of your store.
ย
Installation is straightforward with four 100 foot cables included with your cameras. Each camera provides an autofocused 112-degree view from behind an armored dome.
ย
Each HDD can hold up to 6TB worth of recordings. Plus each camera also has 128 GB of onboard storage.
ย
Kit Features:
- - 4 PoE Ports
- - 5 Megapixel Recording Resolution
- - 4 channel synchronous playbackย
- - 720-pixel playback resolution
- - HDMI/VGA outputs displaying at 1920 x 1080 pixels
- -1 SATA HDD
Once you install your system, be sure to download the Guarding Expert app to your iPhone or Android phone for monitoring everywhere you go. Your system also comes with free DDNS service.
4 CHANNEL NVR SPECS :
NVR SPECS:
ย
|
Video / Audio input |
|
| IP Video input | 4 ch, 4PoE |
| Two-way Audio | 1 ch, RCA |
|
Video/Audio output |
|
| Recording resolution | 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/
ย DCIF/2CIF/CIF/QCIF |
| HDMI/VGA output | HDMI & VGA : simulation |
| Audio output | 1 ch, RCA (Linear, 1kฮฉ) |
| Playback resolution | 5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Synchronous playback | 4ch@720P, 2ch@1080P,1ch@5MP |
|
Hard disk |
|
| Type | 1 SATA interfaces |
| Capacity | Up to 6TB capacity for each HDD |
|
Externalย Interface |
|
| Network interface | 1 x RJ-45 10 /100 /1000 Mbps
ย 4 x10 /100 Mbps PoE Ethernet |
| Input | 40 Mbps |
| Output | 80 Mbps |
| USB interface | 2 x USB2.0 |
|
General |
|
| Power Supply | 100~240VAC, 47~63Hz, 3A |
| Power Consumption | 15 W (without hard disk) |
| Working Temperature | -10 ยฐC ~ +55 ยฐC |
| Working humidity | 10%~90% |
| Chassis | 1U chassis |
| Dimensions | 12.5โ ร 9.5โ ร 2โ |
| Weight | 4.5 lb |
|
CMS/Web/Smartย Phone |
|
| CMS | iCMS |
| Web | 4ch View/4ch Playback |
| Smart Phone Apps | Guarding Expert ( iphone, android)
ย Guarding Expert HD(iPad) |
| DDNS | Free DDNS service |
CAMERA SPECS AND HIGHLIGHTSย
4 Mega Pixel Auto Focus IR Vandal Camera
Features
-4 megapixel High Resolution
-20fps @ 2688ร1520
-Low Illumination
-Auto-focus 2.8~12mm Varifocal lens
-3D DNR & 120dB WDR & BLC
-IP66 Rating
-IR Range up to 100ft
-True Day / Night
-Junction Box available
โConduit pipe holes
(1) 3/4โณ NPT thread w/ Cap (Side)
Digital as well as optical zoom
| Camera | |
| Image Sensor | 1/3โณ Progressive Scan CMOS |
| Minimum Illumination | 0.01 lux @F1.2, AGC ON, 0 lux with IR |
| Shutter Time | 1/30s ~ 1/100,000s |
| Lens | Auto-focus motorized 2.8~12mm @F1.4 Horizontal field of view 112ยฐ~33.8ยฐ |
| Lens Mount | ฮฆ14 |
| Optical Filter | Mechanically Switching IR Filter |
| Noise Reduction | 3D DNR |
| WDR | 120dB WDR |
| On-board Storage | Micro SD/SDHC/SDXC card, Max 128 GB |
| Video Compression | H.264/M-JPEG |
| H.264 Profile | Main profile |
| Bit Rate | 32 Kbps~16Mbps |
| Image | |
| Max Resolution | 2688ร1520 |
| Frame Rate | 20fps (2688ร1520), 30fps (1920 ร 1080), 30fps(1280ร720) |
| Image Settings | Saturation, brightness, contrast adjustable |
| BLC | Yes, zone configurable |
| Network | |
| Network Storage | NAS |
| Alarm Trigger | Line Crossing, Intrusion Detection, Motion detection, tampering alarm, network disconnect, IP address conflict, storage ย exception |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, ICMP,IGMP,SNMP, FTP, 802.1X, QoS, HTTPS |
| Compatibility | ONVIF(Profile S&G), PSIA, CGI |
| General Functionalities (Security) | dualย stream,ย heartbeat,ย mirror,ย passwordย protection,ย privacyย mask, watermark,ย IPย addressย filtering,ย Anonymousย access |
| Network Interface | 1 RJ45, 10 M/100 M Ethernet port |
| General | |
| Power Supply | 12 V DC ยฑ 10%; PoE (802.3af) |
| Power Consumption | Max. 5.5W (7.5W with IR on) |
| Operating Temperature | -30ยฐC ~ 60ยฐC (-22ยฐF ~ 140ยฐF) humidity 95% or less (non-condensing) |
| Impact Protection | exceeding IK10 |
| EXIR Range | Up to 100ft |
| Dimensions | 3.74โ x 4.13โ x10.18โ |
| Weight | 2 lb |
| Weather Proof | IP66 |
